MOT Tools and Equipment – Preparing for a site visit

Prepare For The Inevitable DVSA Site Visit

MOT tools and equipment and tools need to be kept in order.  Here is our advice on how to keep prepared for a site visit

Barry Babister from MOT Juice provides guidance on how you should prepare your MOT  for the inevitable DVSA site review with regards to your MOT tools and equipment.

Barry is a director at MOT Juice and at CCM Garages which own and operate 5 mot bays.

Every MOT bay is required to retain and maintain a bunch of mandatory miscellaneous MOT tools and equipment.

First, let’s get the words from The MOT Testing Guide 6th Edition (revised November 2019)

MOT Testing Guide for Test Stations
The MOT Testing Guide A handbook for Scheme administration Sixth Edition (revised November 2019)

MOT Tools and Equipment

5.6 Miscellaneous Equipment

  1. A tyre tread depth gauge selected from the DVSA’s latest List of Acceptable Equipment
  2. Corrosion assessment tool
  3. Suitable pinch bars, long and short (n/a class 1 & 2)
  4. A steel tape measure (min extended length 1.0 m)
  5. Suitable wheel chocks for the classes of vehicle tested (n/a class 1 & 2)
  6. Brake pedal application device from the DVSA’s latest List of Acceptable Equipment (only mandatory for ATL & OPTL bays)
  7. Suitably positioned mirrors or a colour camera system for lighting checks (only mandatory for ATL & OPTL bays)
  8. A suitable hand-held low voltage inspection lamp
  9. A 13-pin trailer socket test tool from the DVSA’s latest List of Acceptable Equipment (n/a class 1 & 2)
  10. A proprietary leak detection spray which meets BS EN 14291:2004 (n/a class 1 & 2)

In our experience, the tools are somewhere in the MOT bays but no one is ever quite sure exactly where they are especially at the precise time that a Vehicle Examiner asks to see them all.

DVSA guidance on MOT tools and equipment

Here is the guidance given by the DVSA to the Vehicle Examiner.

4.19 Garage Hand Tool Management (VTS)

Are the garage hand tools and workshop equipment stored in a systematic fashion?

Look for evidence that equipment and tools stored tidily and in a readily accessible manner when not in use in appropriate storage facilities e.g. toolboxes, racking and/or shadow boards used, tool retention is monitored.

The last 4 words of the above paragraph ‘tool retention is monitored’ are important. This is because the Vehicle Examiner would like to see a monthly site audit that cross checks that all the tools are available and in good working order. They will also want to see you have a system for alerting and recording if any tools are missing or need replacement or repair.

Remember if the VE finds that your tools are not present he will increase your VTS risk score. You could well fall foul of incorrect test methods too. Not all testable items can be tested correctly without the correct tools.


Whilst we are on the subject of mandatory tools, don’t forget to calibrate that tyre tread depth gauge and record the calibration. For best practice do it every month and for basic compliance every 6 months. Remember that testing with an un-calibrated piece of mandatory equipment attracts serious penalty points. The points can be applied to each individual MOT test carried out using that piece of equipment since its last calibration date expired.

If you don’t fancy building your own site audit system then why not try a free demo of the MOT Juice system as it covers all this and more.

Click here for access to our free to use MOT Juice Demonstration Account


If you would like a simple reminder poster and checklist to put in your mot bay then click the buttons below. There is a choice of two lists. One which can be used as a check list and one that can be used as a memory jogger.

Misc Equipment Reminder Poster

simple misc equipment reminder poster

simple misc equipment reminder poster


The Ultimate Checklist Of Misc Equipment

the ultimate checklist of misc equipment
the ultimate checklist of misc equipment


Need to talk to a human for more information? Lines open Mon-Fri 9-5 on:

01293 911120
